Gasoline generator "Könner & Söhnen" KS 15-1E 1/3 ATSR

Gasoline generator "Könner & Söhnen" KS 15-1E 1/3 ATSR

Name: Gasoline generator "Könner & Söhnen" KS 15-1E 1/3 ATSR
Brand: Könner & Söhnen®
SKU: 4260405363445
Price: 155999.0 UAH
Availability: InStock

Available

₴155 999

Specification

Voltage, V:	230/400
Max/Nominal power (230V), kW:	11.5/11.0
Max/Nominal power (400V), kVA:	15.6/15.0
Engine start:	Electric
Outlets:	1 x CEE 230 V 32 A, 1 x CEE 230 V 63 A

Specification

Voltage, V	230/400
Max/Nominal power (230V), kW	11.5/11.0
Max/Nominal power (400V), kVA	15.6/15.0
Power factor, cosφ	1 (230V)/0.8 (400V)
Frequency, Hz	50**
Current (max.) 230/400 V, A	48/22
Outlets	1 x CEE 230 V 32 A, 1 x CEE 230 V 63 A
Fuel tank volume, l	55
LED display	Voltage, frequency, working hours, oil alarm
Noise level Lpa (7m)/Lwa, dB	72/97
Power output DC, V/А	+
Engine model	KS 780
Engine type	Gasoline powered two-cylinder, four-stroke air-cooled
Engine power, hp/kW	22.0/16.18
Fuel type	Gasoline
Crank case volume, l	1.5
Engine cylinder volume, cm3	750
Power output controller	Intelligent voltage stabilization system AVR
Engine start	Electric
Accumulator (A·h)	36
Alternator winding	Copper
Protection class	IP23M
Net dimensions (LxWxH), mm	797×705×805
Gross dimensions (LxWxH), mm	807×715×905
Net weight, kg	155
Gross weight, kg	170.0
SKU	KS 15-1E 1/3 ATSR
Barcode	4260405363445

Variants

Max Power: 15.6 kW

5.5 kW 8 kW 11.5 kW 15.6 kW

Benefits

Advanced VTS phase switching technology allows for generating power for both single-phase (230V) and three-phase (400V) consumers
A generator with 100% copper windings generates more power compared to a generator with other types of windings
Safety: equipped with safety features such as automatic shutdown in case of overload or low oil levels
The generator can run for a longer period without refueling thanks to the enlarged fuel tank
Uninterrupted power: in case of power supply interruptions, connecting an ATS to the generator will automatically switch the power from the grid to the generator, ensuring continuous operation

Delivery

Fast delivery by Nova Poshta: your order is already with you in 1-3 days!

Payment

Choose a convenient and reliable payment method:

Features

01 High-performance engine

02 Vts system

03 Ergonomic control panel

04 Ats output

05 Alternator with 100% copper winding

06 Steel tank

High-performance engine

Powerful and reliable 2-cylinders air-cooled engine (22 HP), high-performance and costeffective, and conform to European quality standards (including exhaust emissions and noise). Each engine has a corporate K&S stamp and an individual serial number in order to ensure the quality control of manufacture and after-sales service.

Vts system

The unique innovative VTS (Voltage Transfer Switch) phase switching system with equal power for single-phase (230V) and three-phase (400V) with almost no loss of power. Each mode has its own circuit breaker.

Ergonomic control panel

The user-friendly ergonomic control panel allows easy control of the whole device, requires no special skills, and is equipped with sockets designed for removal of full power delivered by the generator and modern LED- display (hour meter, frequency, voltage, oil alarm). PaneI is equipped with engine emergency switc.

Ats output

The ATS (Automatic Transfer Switch) unit automatically starts the generator and transfers load to it when the main power supply is disconnected and automatically stops the generator when the central power supply is restored.

Alternator with 100% copper winding

TM Könner & Söhnen generators are equipped with a high-end synchronous alternator with 100% copper winding. It is only the copper winding that can withstand maximum loads without any damage to ensure long-term reliable operation of the generator set.

Steel tank

“Könner & Söhnen” generators are equipped with an enlarged steel fuel tank (55 l), which extends the generator’s operating time without refueling. The fuel level indicator is located on the tank for ease of use.

Specification

Gasoline generator "Könner & Söhnen" KS 15-1E 1/3 ATSR

Voltage, V	230/400
Max/Nominal power (230V), kW	11.5/11.0
Max/Nominal power (400V), kVA	15.6/15.0
Power factor, cosφ	1 (230V)/0.8 (400V)
Frequency, Hz	50**
Current (max.) 230/400 V, A	48/22
Outlets	1 x CEE 230 V 32 A, 1 x CEE 230 V 63 A
Fuel tank volume, l	55
LED display	Voltage, frequency, working hours, oil alarm
Noise level Lpa (7m)/Lwa, dB	72/97
Power output DC, V/А	+
Engine model	KS 780
Engine type	Gasoline powered two-cylinder, four-stroke air-cooled
Engine power, hp/kW	22.0/16.18
Fuel type	Gasoline
Crank case volume, l	1.5
Engine cylinder volume, cm3	750
Power output controller	Intelligent voltage stabilization system AVR
Engine start	Electric
Accumulator (A·h)	36
Alternator winding	Copper
Protection class	IP23M
Net dimensions (LxWxH), mm	797×705×805
Gross dimensions (LxWxH), mm	807×715×905
Net weight, kg	155
Gross weight, kg	170.0
SKU	KS 15-1E 1/3 ATSR
Barcode	4260405363445

Assembled in PRC.

**In transient modes, the frequency of the generator can change in the short term, that is, during normal operation of the generator, the deviation of the frequency indicator is permissible. Depending on the type of generator, engine and operating mode, the frequency can be 49-54Hz
